VANGUARD 128D

Insert tube beadlock, hutchinson beadlock wheel, 17x9, 16x10, double beadlock wheel assemble offrode tires, very suitable for desert, and rock crawl, mud.

SIZE : 17x9

PCD : 5X114.3, 5X120, 5X127, 5X139.7, 5X150

          6X114.3, 6X130, 6X135, 6X139.7

ET    : -38~-12

Different PCD holes, the ET range is a little different, welcome to contact us for more detials.

Insert tube beadlock wheels, include five parts total, front suface wheel disc, rear wheel rim, bolts, silicon seal ring, tyre tube.

This kind wheel would be very easy to assmeble tyre just by hands.

  1-Developed for the serious off-road enthusiast

  2-Available in 17inch with five and six bolt wheel patterns

  4-Solid A356 aluminum with T6 heat treatment construction

  5-Inner rubber tube included

  6-Reinforced inner lip provides extreme strength and durability

  7-16pcs grade 12.9 zinc-plated beadlock bolts included

  8-Super strong 2600 lbs. load rating

  9-Hub centric fitments for common applications
